PRODUCT INTRODUCTION
It can be used in a wide range of industrial applications, including a cylindrical filter cover, a three-in-one filter cover, and a removable filter cover for pharmaceutical industry To lift the stirring drive device. This kind of filter often works under pressure or vacuum. It has a heating jacketed agitator and a bottom discharge valve. Anfd has high stability and high wear resistance to strong corrosive media; it is suitable for products sensitive to metal, pollution or temperature; it has a wide range of operating temperature and pressure; it is the best choice to replace Hastelloy; the side discharge valve adopts PTFE or FEP seal ring soft sealing; the anfd is suitable for metal, pollution or temperature sensitive products; In order to ensure the sealing performance of the side discharge valve, it is equipped with automatic or manual sealing surface cleaning device; hook type clasp bolt is used to fix the main flange; PTFE filter plate or filter cloth is used as the filter medium; double face mechanical seal suitable for chemical or aseptic process; CIP and SIP operation can be completed; manual or automatic tail discharge device; GMP standard is met and FDA certification is obtained.
DESIGN PARAMETERS
1、Nominal filtration area: 0.38 ~ 5.3㎡
2、Inner diameter of tank: 700 ~ 2600 mm
3、Volume: 0.25 ~ 5m³
4、Filter cake thickness: 200 ~ 400mm
5、Jacket design pressure: 0.6 MPa
6、Design operating temperature: 0 to 180 ℃
7、Thickness of enamel layer: 0.8 ~ 2.0mm
8、Agitator motor and reducer: three phase asynchronous motor (explosion proof type optional) + vertical reducer (optional type)
9、Shaft seal type: double face mechanical seal
10、Metal material and weld inspection: magnetic particle inspection and X-ray inspection
11、Metal porcelain layer inspection: surface finish, thickness and electric spark test: 20kV non breakdown porcelain layer and weld inspection: magnetic particle inspection, X-ray inspection
12、Hydrostatic test: Tank: according to design pressure; jacket: 0.6MPa
13、The main dimensions of the equipment refer to JB / T 20099-2007 standard and are improved on this basis; non standard customized products with special requirements of customers can also be accepted.
PRODUCT AND SERVICE ADVANTAGES
Corrosion resistance - glass lining is extremely resistant to acid and alkali corrosion (except hydrofluoric acid and hot concentrated phosphoric acid)
Impact resistance - glass lining has low internal stress, high strength and mechanical impact resistance up to 260 * 10-3 J
Thermal properties - high temperature resistance, thermal conductivity is only 1 / 100 - 1 / 1000 of pure metal products
Insulation - 20kV high frequency electric spark cannot break through glass lining
Anti adhesion - many substances will not adhere to the glass surface, but will adhere to the metal surface
High purity - glass lining with high quality standards for food and pharmaceutical applications
Flexibility - more practical equipment can be designed according to various chemical conditions, easy to clean - glass lined surfaces can be cleaned and disinfected quickly and easily
No Catalysis - eliminates the possibility of catalysis in containers made of various rare metals
Economy - cost comparable to stainless steel and most alloys
Excellent product quality - CNC machining and welding equipment with high precision; underground electric furnace is used for enameling furnace, with precise temperature control and even lining
Short lead time - standard model products, the company has a large stock, delivery time can be as soon as one week
Quick response to after-sales service - the hotline provides 24-hour service and can arrive at the customer's site within 72 hours to deal with the problem
Long warranty period - the warranty period can be as long as 12-18 months. The company is responsible for handling the quality problems caused by non-human factors during the warranty period, and replacing the fault spare parts free of charge
Many service outlets - the company has service agents in the northeast, southwest and northwest regions, and the company in other regions will send personnel to deal with it directly
